Custom made Trailers

Key Features

1000L IBC tank capacity
Heavy duty single axle
2000 GVM rating
Fully welded steel chassis
Australian made
ADR compliant lighting

Chassis and Frame

The trailer frame is constructed from heavy duty RHS steel with a reinforced tank cradle. The A frame drawbar provides extra strength and towing stability. Available in painted or hot dipped galvanised finish.

Suspension

Heavy duty leaf spring suspension rated to 2000 kg.
Solid axle with durable hubs.
Designed to handle dynamic water movement during braking and cornering.

Water is a moving load. Proper suspension reduces sway and improves towing control, especially when the tank is full.

Braking

Mechanical override disc brakes fitted as standard for 2000 GVM.
Electric brake upgrade available if required.

Coupling

50 mm heavy duty coupling
Safety chains compliant with NSW regulations
Jockey wheel fitted

Tyres and Wheels

14 inch light truck tyres
Black steel rims
Spare wheel mounted on drawbar

Dimensions

Overall length approximately 3200 mm
Overall width approximately 1800 mm
Tank platform designed to fit standard 1000L IBC

Who This Trailer Suits

Landscapers
Pressure washing businesses
Civil contractors
Rural property owners
Event water supply

Optional Extras

Pump mounting bracket
Hose reel mount
Toolbox
Stone guard
Upgraded electric brakes
Custom tie down system

Pre Order and Deposit Policy

All Great Western Trailers are built to order. To secure your trailer in our production schedule, a 50 percent deposit is required at the time of order confirmation.

The remaining balance is payable prior to collection or delivery.

Production Time

Build times vary depending on trailer model and custom options selected. Estimated lead times will be confirmed at the time of order.

Deposit Terms

A 50 percent deposit confirms your order and secures materials and manufacturing allocation. Production will not commence until the deposit has been received.

Deposits are non refundable once fabrication has commenced, as materials and labour are allocated specifically to your trailer build.

Final Payment

The remaining balance must be paid in full prior to pickup or dispatch. Delivery arrangements will be confirmed once final payment has been received.

Order Changes

Any changes to specifications after deposit may affect pricing and production timelines.
